Toa PC-1860 Ceiling Mount Speaker

Price : To be announced Regular Price : ~~৳ 0~~ Status : Pre Order Code : PC-1860 Brand : TOA

Key Features

Model : PC-1860
Frequency : 80 Hz - 20 kHz
Dimensions : φ180 × 70 (D) mm (φ7.09" × 2.76")
Weight: 560 g (1.23 lb)
Rated Input : 6 W (100 V line),

View More Info

প্রযুক্তি পণ্যের অস্থিতিশীল বাজার পরিস্থিতির কারণে যেকোন সময় মূল্য পরিবর্তন হতে পারে। হেল্পলাইন নাম্বারে কল দিয়ে পণ্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেওয়ার অনুরোধ রইলো

Specification
Description
Videos
FAQ
Reviews (0)

Specification

Description

Toa PC-1860 Ceiling Mount Speaker

All metallic construction, ideal for use in a voice alarm system or BGM system. It feature spring clamp mechanism for easy mounting to the ceiling. The input impedance can be easily changed by changing the tap position of the transformer. The push-in type input terminal block makes cable connection easy and allow bridge wiring.

Rated Input	6 W (100 V line), 3 W (70 V line)
Rated Impedance	100 V line: 1.7 kΩ (6 W), 3.3 kΩ (3 W), 6.7 kΩ (1.5 W), 13 kΩ (0.8 W) 70 V line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W), 6.7 kΩ (0.8 W), 13 kΩ (0.4 W)
Sensitivity	94 dB (1 W, 1 m) (500 Hz - 5 kHz, pink noise)
Frequency Response	80 Hz - 20 kHz (peak -20 dB)
Speaker Component	12 cm (5") cone-type
Operating Temperature	-10 °C to + 50 °C (14 °F to 122 °F)
Dimensions for Fixing Hole	Mounting hole: φ150±3 mm (φ5.91"±0.12") Ceiling thickness: 5 - 25 mm (0.2" - 0.98")
Speaker Mounting Method	Spring clamp
Applicable Cable	Solid wire: 0.5 - 3 mm² (AWG 20 - 12)
Connection	Push wire connection (bridging terminal-2 branch type)
Finish	Frame: Steel plate, white (RAL 9016 equivalent), paint Grille: Steel net, white (RAL 9016 equivalent), paint
Dimensions	φ180 × 70 (D) mm (φ7.09" × 2.76")
Weight	560 g (1.23 lb)
Accessory	Paper pattern …1
